2ton Fully Electric Stacker

Capacity:2000KG
Dead weight:570/598/625/653KG
Lithium Battery:24V/85AH

Product Introduction

In modern warehousing and logistics operations, our newly launched 2-ton all-electric walk-behind stacker has become a reliable choice for improving operating efficiency with its excellent carrying capacity and intelligent design. This stacker adopts a standard steel gantry structure, has excellent impact resistance and wear resistance, and fully meets the needs of high-intensity handling. The 48V/45Ah high-performance battery is combined with a 210 high-power drive system, with strong and stable power output, which can easily cope with the 2-ton load demand and ensure long-term continuous operation without chain failure.

1001
2001
3001
4001

This product is equipped with a Jinpeng intelligent controller to accurately control the lifting and driving speed, with sensitive operation response and smooth operation. The golden combination of 1KW drive motor and 2.2KW lifting motor not only ensures the flexibility of driving, but also ensures the efficient and stable lifting process. The use of Zhongli's same-factory oil cylinder and accelerator makes the equipment run more smoothly and reliably, effectively extending its service life. The configuration of forklift-specific batteries has a long cycle life and supports fast charging, which greatly improves the efficiency of equipment use.



In terms of safety performance, the innovative reverse emergency stop switch design will automatically reverse when the equipment touches the operator, effectively avoiding the risk of squeezing and providing all-round safety protection for the operator. The whole machine adopts a humanized design, which is simple and convenient to operate, and even novices can quickly get started. Key components are all made of high-quality original accessories, with low failure rate and simple maintenance, which greatly reduces the cost of use.



This 2-ton stacker is particularly suitable for heavy-duty handling needs in e-commerce warehousing, logistics distribution, production and manufacturing. In large storage centers, it can easily cope with the stacking of pallet goods; in production workshops, it can efficiently complete the transfer of raw materials and finished products; in the logistics distribution link, it can significantly improve the loading and unloading efficiency. The equipment has a compact structure and a small turning radius, and can operate flexibly even in narrow spaces.

We sincerely invite you to experience this professional handling equipment that combines large load, high safety and intelligence. Contact our sales team immediately to get more product information and exclusive quotes, and let our professional stacker solutions bring a qualitative leap to your warehousing and logistics operations! Choose our 2-ton all-electric walk-behind stacker to make heavy-load handling easier, safer and more efficient!

5



Feature

unit



Model



CDD20HA

Load capacity

Q(kg)

2000

Load center

C(mm)

500

Wheel base

Y(mm)

1285

0perating type



Walking

Wheels



Wheels type



PU

Wheel quantity Driving wheel/Bearing wheel



1/1/4

Driving wheel size



ɸ210×75

Bearing wheel size



ɸ80×70(Double wheels)

Dimension



Maximum lifting height

h1 (mm)

2000/2500/3000/3500

Mast lowered

h2 (mm)

1485/1735/1985/2235

Max height(mast lifted with backrest)

h3 (mm)

2450/2S50/3450/3950

Min.fork lowered height

S1(mm)

85

Overall fork width

B1(mm)

560/680

Inside width between forks

B2(mm)

240/360

Fork length

L1(mm)

1150(Customizable)

Fork width

S (mm)

185

Fork thickness

e (mm)

55

Min frounf height

S2 (mm)

30

0verall length(With /Without handle)

L(mm)

1742

0verall width

B (mm)

800

0verallheight(With handle)

h4 (mm)

1305

0verallheight(Without handle)

h5 (mm)

855

Min.Turning radius

Wa (mm)

1462

Min.Aisle width for pallets 800x1200

Ast (mm)

2195

Min.Aisle width for pallets 1000x1200

Ast (mm)

2280

Performance



Travel speed(laden/unladen)

km/h

4.5/5

Lift speed(laden/unladen)

mm/'s

85/120

Lowering speed(laden/unladen)

mm/s

50/100

Gradeability(laden/unladen)



5/7

Electrical configuration



Drive motor

kW

1.0

Lift motor

kW

2.2

Battery voltage/capacity

V/Ah

48V/45Ah

Brake



Electromagnetic/Regenerative

Controller



Jinpeng Specia

Weight



Battery weight

kg

4×12

Serviceweight with battery

kg

570/598/625/653



6

7

8

9
