3.5T
video
3.5T

3.5T Solid Lithium Battery Forklift

Lifting Capacity:3500KG
Total Weight:4900KG
Lithium Battery:80V/480AH

Product Introduction

231

3.5-Ton Solid-State Lithium Forklift: The Future of Heavy-Duty Material Handling

In industrial operations where power, efficiency, and reliability are non-negotiable, the 3.5-ton solid-state lithium forklift redefines what's possible in heavy-load material handling. Engineered for maximum uptime and effortless operation, this powerhouse combines military-grade durability with next-generation energy technology , making it the ultimate choice for demanding environments like ports, steel yards, and large-scale manufacturing.

Unstoppable Performance, Unmatched Efficiency

At the heart of this forklift lies a revolutionary solid-state lithium battery , delivering instant torque, consistent power, and ultra-fast charging -without the performance fade of traditional lithium-ion or lead-acid alternatives. Unlike conventional forklifts, it maintains peak efficiency even in extreme temperatures, ensuring reliable operation in freezing warehouses or scorching outdoor yards.

Innovative Side-Pull Battery System for Maximum Uptime

A game-changer in industrial logistics, the patented side-pull battery design eliminates downtime. Instead of lengthy battery swaps or complex charging setups, operators can seamlessly replace the battery in minutes -keeping productivity flowing around the clock. This system is ideal for 24/7 operations , where every second counts, and traditional charging cycles would disrupt workflow.

Operator-Focused, Safety-Enhanced

Designed for long shifts without fatigue , the spacious cabin features ergonomic controls, adjustable suspension seating, and 360° visibility . Advanced safety systems, including automatic load stabilization and collision avoidance , work silently in the background, reducing risk in high-traffic areas.

The Sustainable Heavy-Lift Solution

With zero emissions, near-silent operation, and 50% lower energy costs than diesel alternatives, this forklift doesn't just meet sustainability goals-it exceeds them. The solid-state battery's 10,000+ cycle lifespan means years of maintenance-free service, slashing total cost of ownership.

For industries that demand power without compromise , the 3.5-ton solid-state lithium forklift is more than equipment-it's the future of heavy material handling. Stronger. Smarter. Unstoppable.

Manufacturer



UPPER FORK

Product model



CPCD35T-SJ6

Power mode



Lithium battery

Driving mode



Drive

Rated lifting capacity

Q(kg)

3500

Load center distance

c(mm)

500

Front overhang

x(mm)

485

Wheelbase

y(mm)

1680

Deadweight (including battery)

kg

4900

Tyre type



Solid tire

Front wheel specifications



28x9-15

Rear wheel specifications



21x8-9

Front track

b10(mm)

1000

Rear track

b11(mm)

990

Mast tilt (front/rear)

α/β(°)

6°/12°

Mast static height

h1(mm)

2070

Free lifting height

h2(mm)

150

Standard mast lifting height

h3(mm)

3000

Maximum mast lifting height (with shelf)

h4(mm)

4120

Overhead guard height

h6(mm)

2180

Total length (without fork)

l2(mm)

2555

Total width

b1(mm)

1225

Fork specifications

l/e/s(mm)

1070×125×50

Outer turning radius

Wa(mm)

2280

Operating speed (full load)

km/h

12

Operating speed (no load)

km/h

13

Lifting speed (full load)

mm/s

320

Lifting speed (no load)

mm/s

460

Maximum climbing grade (full load)

%

15

Maximum climbing grade (no load)

%

20

Service brake



Hydraulic

Parking brake



Mechanical

Rated power of travel motor (S2-60min)

kw

10

Peak power of travel motor (2min)

kw

16

Rated power of lifting motor (S3-15%)

kw

16

Peak power of lifting motor (2min)

kw

20

Battery voltage/capacity

V/Ah

80V/480Ah

Control mode



MOS/AC

Controller manufacturer



SANTROLL

Working pressure

Mpa

18.5
